Qhuav hmoov Putty hmoov of elevator



TH series nplhaib saw thoob lub elevator yog tsim rau ntsug conveying ntawm hmoov, granular thiab me me thaiv cov ntaub ntawv tsis muaj kev sib tsoo thiab me me sib tsoo. TH hom nplhaib saw thoob of elevator yog ib hom kev sib txuas ntawm lub thoob of elevator, uas siv cov khoom sib xyaw lossis lub ntiajteb txawj nqus unloading thiab khawb hom loading. TH hom nplhaib saw thoob lub elevator yog tsim rau conveying hmoov, granular thiab me me thaiv hauv qab sib tsoo cov ntaub ntawv uas nws bulk ntom yog tsawg dua 1.5t / m³, thiab cov khoom kub yog qis dua 250 degree. Xws li: thee, cement, gravel, xuab zeb, chiv, nplej, thiab lwm yam.







1. Loj conveying muaj peev xwm: Piv nrog tib tus qauv HL, lub peev xwm conveying yog ze li ob npaug;

2. Nws yog ib qho yooj yim los hloov thiab txuag nqi. Vim yog siv cov sprocket sib dhos, lub log lub cev thiab lub npoo txuas nrog siab - lub zog bolts. Thaum lub sprocket hnav mus rau ib qho twg, cov bolts tuaj yeem raug unscrewed thiab lub npoo tuaj yeem raug tshem tawm thiab hloov, uas yooj yim rau kev hloov. Yog li txo cov nqi tu.

3. Tsis tshua muaj suab nrov, raws li kev tiv thaiv ib puag ncig tam sim no, cov khoom siv kis tau tus mob txais ZLY hom reducer, uas yog ib hom tshiab ntawm cov hniav tawv nqaij reducer ua raws li ZBJ19004-88 tus qauv, thiab cov iav yog refined los ntawm carburizing, quenching, sib tsoo thiab lwm yam txheej txheem, muaj qhov zoo ntawm qhov me me, lub teeb yuag, tsis muaj peev xwm ua haujlwm siab, lub neej ntev, siab ua haujlwm.

4. Cov cuab yeej kis tau tus mob yog nruab nrog lub backstop, uas tuaj yeem tiv thaiv qhov tshwm sim ntawm "kev tawm tswv yim".

5. Lub traction ib feem yog siab -lub zog ncig saw ua los ntawm qis- hlau alloy. Tom qab kev kho cua sov tsim nyog, nws muaj qhov zoo ntawm lub zog tensile siab, hnav tsis kam thiab ua haujlwm ntev.

6. TH hom nplhaib saw thoob elevator muaj ob hom hoppers: ZH (nruab nrab- lub thoob tob) feem ntau haum rau kev thauj cov ntub dej, yooj yim -caking, thiab nyuaj -rau- pov cov ntaub ntawv, xws li cov xuab zeb ntub, molding xuab zeb, chiv, {5} hom hmoov SH, thiab lwm yam. conveying qhuav, xoob thiab yooj yim pov cov ntaub ntawv, xws li cov cement, clinker, gravel, thee, thiab lwm yam, thiab nws lub peev xwm conveying kuj loj dua li ntawm ZH hom.





Qauv	Kev muaj peev xwm		Hopper			Transmission sprocket ceev(r / min)	Towing qhov chaw
	ZH(m3/h)	SH(m3/h)	Hopper muaj peev xwm (L)		Hopper sib nrug(mm)		Chain Specifications	Ntiv nplhaib nuv specification	thauj(KN)
			ZH	SH
TIAB SA 315	37	58	3.7	5.8	512	42.5	φ18×64-7	φ18×64-M14	Ntau dua lossis sib npaug rau 320
TSI 400	58	92	5.9	9.4	512	37.6	φ18×64-7	φ18×64-M14	Ntau dua lossis sib npaug rau 320
TSI 500	81	129	9.3	15	688	35.8	φ22×86-7	φ22×86-M18	Ntau dua lossis sib npaug rau 480
TSI 630	144	207	14.6	23.5	688	31.8	φ22×86-7	φ22×86-M18	Ntau dua lossis sib npaug rau 480



Nco tseg:
1. Lub thoob ntim rau hauv lub rooj yog xam lub thoob ntim, thiab lub ntim ntim tau xam raws li qhov ntim ntawm 0.6.

2. TH hom thoob of elevator hopper daim ntawv thov:

Zh - Nruab nrab thoob thoob: xa cov ntaub ntawv ntub dej, xws li qab zib, cov xuab zeb ntub dej, thiab lwm yam.

Sh--lub thoob tob: xa cov hmoov hnyav thiab cov khoom thaiv me me, xws li cov cement, xuab zeb, thee, thiab lwm yam.







Qhuav hmoov putty hmoov of elevatorqauv

Lub cev muaj zog reducer 2, sab sauv sprocket 3, bearing 4, txij nkawm platform 5, noj chaw nres nkoj 6, ntsia liaj qhov rooj kev twb kev txuas 7, saw 8, hopper 9, noj chaw nres nkoj 10, ntsia hlau nro 11, soj ntsuam chaw nres nkoj 12, sab sab Sprocket 13, bearing thiab bearing rooj 14, nruab nrab multi-section box
Muaj ob hom hoppers (cov thoob sib sib zog nqus) rau TH hom nplhaib saw thoob elevator series:

ZH hom(nruab nrab thoob thoob) feem ntau yog siv los thauj cov ntub dej, agglomerated thiab nyuaj rau pov cov ntaub ntawv, xws li cov xuab zeb ntub, molding xuab zeb, chiv, alkali hmoov, thiab lwm yam.

SH hom(lub thoob tob) feem ntau yog siv los thauj cov khoom qhuav, xoob thiab yooj yim pov tseg, xws li cov cement, gravel, thee, thiab lwm yam.

TH homQhuav hmoov putty hmoov of elevatorhopper daim ntawv thov (them thoob)

Q-- Pem hauv ntej hopper:xa cov ntaub ntawv uas ntub dej, yooj yim rau agglomerate thiab nyuaj rau pov, xws li ntub xuab zeb, ntub coal, thiab lwm yam.

S - tob puag ncig hauv qab hopper:conveying qhuav, xoob thiab yooj yim pov cov ntaub ntawv, xws li cement, thee, crushed pob zeb, thiab lwm yam.





Kev lag luam tshuaj:resin, xim, tshuaj, tshuaj, tshuaj pleev ib ce, tua hluav taws tus neeg sawv cev, yas hmoov, abrasive iav, thiab lwm yam.

Kev lag luam ceramic:abrasives, alumina, porcelain av nkos, av nplaum av, iav hmoov, cov ntaub ntawv refractory, quartz xuab zeb, PVC resin hmoov, citric acid, polyethylene hmoov, ntxhua hmoov, thiab lwm yam.

Kev lag luam zaub mov:qab zib, monosodium glutamate hmoov, ntsev, kua txiv hmab txiv ntoo, hmoov txhuv nplej siab, mis hmoov, zaub mov, kua mis, qe hmoov, nplej noodles, soy sauce, ntses hmoov, kua txiv pineapple, thiab lwm yam.

Kev lag luam metallurgical:carbon dub, cosolvents, activated carbon, pearls, thiab lwm yam.







1. Ua ntej siv lub thoob of the elevator, koj yuav tsum khiav lub tsheb khoob ib ntus txhawm rau saib seb cov khoom siv traction puas ua haujlwm zoo li cas, seb puas muaj cov saw jamming, saw skipping, slippage thiab deviation, thiab seb cov fasteners puas xoob. Yog tias muaj teeb meem tshwm sim, nws yuav tsum tau kuaj xyuas tam sim ntawd thiab kho kom raws sijhawm.

2. Tom qab khiav tau ob peb teev, qhov kub ntawm cov kabmob yuav tsum tsis txhob siab tshaj 60 degrees, thiab lubrication thiab sealing kev ua tau zoo yuav tsum tau khaws cia zoo. Lub reducer tsis muaj roj to thiab tsis muaj suab nrov.

3. Cov traction qhov chaw (xws li chains los yog tapes) yuav tsum tuav ib tug tej yam kev nro. Yog hais tias muaj slack nyob rau hauv lub traction qhov chaw, lub hopper yuav yooj yim ntaus lub casing, uas yuav ua rau lub casing thiab lub hopper hnav thiab tsoo ntxov ntxov.

4. Koj yuav tsum nco ntsoov saib xyuas seb qhov nruj ntawm ob txoj hlua khi zoo li cas, txwv tsis pub lub hopper yuav yooj yim skewed, uas yuav ua rau cov khoom thauj tsis sib xws, thiab nws yooj yim rau cov saw hlau kom poob ntawm qhov sib kis sprocket thiab ua rau muaj kev sib tsoo.

5. Nco ntsoov xyuas seb txoj siv conveyor puas raug torn, seb cov saw hlau puas hnav lossis tawg, thiab yuav tsum tau hloov tam sim ntawd thaum pom cov xwm txheej no.

6. Tsis tu ncua xyuas seb qhov kho ntawm lub hopper puas nyob rau hauv qhov zoo.

7. Lub backstop yuav tsum tau tshuaj xyuas tsis tu ncua kom ntseeg tau tias kev ua haujlwm ruaj khov thiab xyuas kom tsis txhob thim rov qab vim kev sib tsoo.

8. Thaum txhim kho lub casing, xyuas kom meej tias nws cov installation raug kom tsis txhob muaj lub hopper sib tsoo nrog lub casing thaum lub sijhawm ua haujlwm.

9. Txhua qhov lubricating yuav tsum tau lubricated nruj raws li qhov yuav tsum tau ua.

10. Tsis tu ncua tswj thiab ntxuav cov khoom txav, thiab xyuas qhov hnav ntawm chains, sprockets, kis tau tus mob siv, rollers, thiab hoppers. Kev tshuaj xyuas yuav tsum tau ua tom qab nres thiab tshem tawm cov khoom siv hluav taws xob.

11. Nco ntsoov xyuas lub thoob of the elevator kom pom tias muaj qhov loj - txoj kab uas hla thaiv cov khoom tawv lossis lwm yam impurities thaiv nyob rau hauv qis qis ntawm lub elevator.

12. Tsis tu ncua xyuas thiab kho cov cuab yeej tensioning kom cov tswvcuab traction nrog kev ua haujlwm nruj.





Lub npe ntawm lubricating qhov	Lubricating khoom	Lubrication voj voog	Txoj kev lubrication
Cov kabmob	Dej Resistant Roj	200 teev	nrog lub lubricator
Backstop	Dej Resistant Roj	50 hnu	nrog lub lubricator
Tension Bolt	Dej Resistant Roj	500 teev	smear
Ceev reducer	Raws li qhov tshwj xeeb ntawm lub nruab reducer	6 hli	ncuav
Fais Tsav	Dej Resistant Roj	6 hli	ncuav





Ua ntej-Kev Muag Khoom:

• Qhia cov neeg siv khoom kom xaiv cov khoom siv tsim nyog.
• Xa cov neeg ua haujlwm engineering thiab cov kws tshaj lij mus rau qhov chaw tsim khoom hauv lub sijhawm los npaj lub xaib rau cov neeg siv khoom, tsim cov txheej txheem tsim nyog thiab kev daws teeb meem.
• Peb tuaj yeem tsim thiab tsim cov khoom raws li cov kev xav tau tshwj xeeb ntawm cov neeg siv khoom kom tau raws li cov kev xav tau sib txawv ntawm cov tub ua lag luam



Ntawm Kev Muag Khoom:

• Kev soj ntsuam nruj ntawm cov khoom ua ntej tawm hauv lub hoobkas
• Nkoj raws li daim ntawv cog lus



Tom qab-muag Service:

• Lub sijhawm lav tseem ceeb ntawm cov khoom muag los ntawm peb lub tuam txhab yog ib xyoos (tshwj tsis yog qhov tsis ua haujlwm lossis kev puas tsuaj los ntawm tib neeg cov yam ntxwv, roj yam tseem ceeb lossis qhov tshwm sim tsis zoo, thiab qhov tsis zoo yuav tsis them los ntawm lub warranty: roj injectors, twj tso kua mis, lub qhov muag photosensitive, thiab lwm yam).
• Yog tias cov khoom siv tsis ua haujlwm yog tshwm sim los ntawm tib neeg yam, tus nqi yuav raug them raws li lub Hoobkas nqi.
• Tom qab tau txais daim ntawv ceeb toom lav, teb tsis pub dhau 2 teev . 24 teev cov kev taw qhia kev daws teeb meem.







Zhengzhou Odifei Machinery Equipment Co., Ltd. tau tsom mus rau cov khoom siv conveying rau 17 xyoo. Nws lub lag luam tseem ceeb yog: kauv vibration ntsug elevator, slat feeder, saw phaj conveyor, slat conveyor, scraper conveyor, lub kaum loj txoj siv conveyor, ntsia hlau conveyor Conveyor, saw thoob conveyor, TD siv thoob of elevator, TH nplhaib saw thoob of elevator, NE thoob ntau yam ntawm cov thoob elevator, thiab lwm yam. thoob elevator. TD75 siv conveyor (los yog siv conveyor), mobile conveyor, siv conveyor nrog loj inclination kaum sab xis; ntsia hlau conveyor, shaftless ntsia hlau conveyor; lub teeb, nruab nrab thiab hnyav saw phaj conveyor; saw thoob conveyor tshuab, SCD trough clinker conveyor; kab rov tav ob chav ncej tov khoom; lub teeb, nruab nrab thiab hnyav phaj feeder; GZG lub cev muaj zog vibration feeder; trommel screen, shaftless trommel npo;

Xyoo 2010, peb lub tuam txhab R & D pab neeg tau nkag mus rau hauv kev lag luam kev lag luam, thiab tau tsim kho cov khoom pov tseg hauv tsev kho mob scaly conveyors, kev tshuaj xyuas cov khib nyiab hauv tsev thiab txheeb xyuas cov ntxaij vab tshaus trommel, kev tsim cov khib nyiab slat feeders, thiab hluav taws xob arc rauv scaly scrap conveyors, uas tsis tsuas yog tsim Nws kuj tsim lub hom phiaj ntawm kev lag luam thiab ib puag ncig cov txiaj ntsig. saw hlau.

Zhengzhou Odifei Machinery Equipment Co., Ltd. tau ua tsis tu ncua kev siv technology tshiab nyob rau hauv tus ntsuj plig ntawm kev ua tau zoo, thiab tau tsim ntau yam khoom siv tshiab. Cov khoom lag luam yog qib siab hauv kev tsim, nplua hauv kev tsim khoom, txhim khu kev qha hauv kev ua tau zoo, muaj qib siab thoob ntiaj teb, muag zoo hauv tsev thiab txawv teb chaws, thiab lub hom phiaj ua tus thawj coj hauv kev lag luam!





Q: Koj puas yog lub Hoobkas lossis tuam txhab lag luam? Thaum tsim ibQhuav hmoov putty hmoov of elevator, Dab tsi lwm cov ntaub ntawv yog thoob elevator haum rau?

A: Peb yog lub Hoobkas, tsim nyob rau xyoo 2007, tshwj xeeb hauv kev tsim cov ntsug vibration hoists, ntsug vibration of elevator, thoob elevator, siv conveyors, nplai conveyors, ntsia hlau conveyors, thiab lwm yam. Lub thoob elevator tuaj yeem siv rau hauv kev lag luam chemical, ceramic, kev lag luam khoom noj khoom haus, metallurgical kev lag luam, thiab lwm yam.



Q: Yuav ua li cas txog cov khoom seem?

A: Peb ib txwm muab cov khoom seem ntawm tus nqi thiab muab cov npe ntawm cov khoom seem rau koj thaum koj yuav lub tshuab.



Q: Koj puas yuav sim Crushed ore phaj saw thoob of elevator ua ntej xa khoom?

A: Yog lawm, peb yuav sim txhua lub tshuab thiab cov kab ntau lawm ua ntej xa khoom, thiab xa cov yeeb yaj kiab ua haujlwm rau koj. Koj tuaj yeem tshawb xyuas nrog peb ua ntej xa khoom.



Q: Dab tsi yog vim li cas rau kev rov qab pub mis ntawm lub thoob of elevator thaum ua haujlwm?

A: Yog tias kev pub mis ntau dhau los yog tsis sib xws, tswj kev pub mis.



Q: Dab tsi yog qhov txawv ntawm NE thoob of elevator, nplhaib saw of elevator thiab siv elevator, thiab yuav xaiv lawv li cas?

A: Feem ntau, peb tuaj yeem siv dav dav. Cov khoom nqa los ntawm txoj siv elevator tsis tuaj yeem siab dhau. NE elevator muaj peev xwm nqa loj.



Q: Yuav ua li cas xyuas thiab daws qhov muaj zog viav vias ntawm lub thoob of elevator?

A: Kev kuaj xyuas cov bolts thiab ceev cov saw hlau yuav pab daws qhov teeb meem no.



Q: Yuav ua li cas rau nruab thoob of elevator?

A: Kev teeb tsa cov cuab yeej siv tau yooj yim tuaj yeem coj mus deb, thiab cov kab ntau lawm lossis cov khoom siv kho kom haum tuaj yeem npaj nrog cov kws tshaj lij los coj kev teeb tsa thiab kev debugging ntawm qhov chaw.











Cov neeg yuav khoom yuav tsum muab cov kev txwv hauv qab no:

Khoom npe, lub ntiajteb txawj nqus tshwj xeeb, nqa tus nqi / teev, nqa qhov siab, khoom siv, puas muaj lwm yam tshwj xeeb?

Yog tias koj txaus siab rau Dry hmoov putty hmoov of elevator, thov koj xav tiv tauj peb hauv 24 teev!

Txais tos koj tuaj xyuas peb lub Hoobkas !!!
